Universal plow tip, hydraulic reversible plow accessories, high-strength wear-resistant head

Short Description:

The plow tip, an auxiliary component for agricultural machinery, is forged from high-strength, wear-resistant steel and undergoes a special heat treatment process, resulting in extremely high hardness and excellent toughness. Its streamlined wedge-shaped entry design significantly reduces tillage resistance, provides precise soil entry angles, and delivers strong penetration. Suitable for various soil environments, its wear resistance is several times higher than ordinary plow tips, effectively protecting the main plow body and significantly extending the overall service life of the equipment, making it an ideal choice for efficient tillage.

Send email to us

Product Detail

Product Tags

The plow tip, as the foremost contact component in moldboard plows and combined tillage machinery, is hailed as the "soil-breaking pioneer." This product is specifically designed to withstand high-intensity, high-load agricultural operations and is a core wear part that ensures the plow's soil penetration performance and reduces operating resistance. Whether it's deep plowing and loosening or shallow turning and stubble removal, a high-quality plow tip directly determines the overall operating efficiency and service life of the agricultural machinery.

High-manganese steel series: Suitable for harsh terrain with abundant gravel and high impact. When subjected to strong impact, the surface of this material rapidly hardens, with the hardness increasing dramatically from HB200 to over HB500. It becomes harder with repeated impacts, effectively preventing cracking.

High-chromium alloy series: Specifically designed for sandy soils or large-scale plain operations. Through advanced overall heat treatment, the hardness is evenly distributed (HRC 50-55), and its wear resistance is 3-5 times that of ordinary 65Mn steel, significantly reducing the frequency of downtime for replacement in the field.

Sharp Cutting Edge and Strong Soil-Crushing Power: Utilizing a streamlined wedge design with a precisely calculated tip angle, it instantly cuts through the soil, significantly reducing tractor traction resistance and achieving an overall fuel saving rate of 8%-12%.

Self-Sharpening Function: A unique bimetallic composite structure or biomimetic streamlined design ensures the cutting edge remains sharp throughout operation, preventing "stacking" caused by dulling and guaranteeing consistent tillage depth.

Standardized Installation: Strictly adhering to international standards, bolt hole accuracy is controlled within ±0.5mm, allowing for seamless installation with various reversible plows and grid plows. No on-site cutting or grinding is required, making installation convenient and time-saving.
