Plow Tip 622128/622129 Reversible Double Point

Short Description:

The Plow Tip 622128/622129 is a double-headed reversible plow tip forged from high-strength boron steel or alloy steel, and is a core tillage component of the tractor-mounted plow body. Its unique symmetrical design provides two sharp working ends. If one end wears out, it can be easily disassembled and rotated 180° to replace the worn end, achieving a “one-for-two” effect and effectively reducing replacement frequency and long-term operating costs. This product undergoes a precise heat treatment process, achieving a cutting edge hardness of HRC 48-55, combining excellent wear resistance and impact toughness. It can efficiently break up and till soil under various soil conditions, significantly improving agricultural operational efficiency.

Send email to us

Product Detail

Product Tags

Plow Tip 622128 and 622129 are core wear-resistant components for moldboard plowing operations, commonly referred to as double-headed plow tips or replaceable plowshares. As the components that come into direct contact with the soil and bear the greatest friction and impact during tillage, these two products feature a unique symmetrical double-headed structure design, designed to provide agricultural machinery with an efficient and economical soil tillage solution.

The most distinctive feature of these two products is their symmetrical dual-head design. Each plow tip is equipped with two sharp working ends. When one end becomes dull due to prolonged friction with sand, gravel, and hard soil during cultivation, the operator does not need to immediately replace the entire set of parts. Simply disassemble, flip the plow tip 180 degrees, and reinstall it. The brand-new other end is ready to be used, and the cutting effect is as sharp as a new product.

This ingenious design makes the total service life of the accessory twice that of a traditional single-head plow tip, significantly reducing the frequency of downtime for replacement in the field, greatly reducing the cost per unit cultivated area, and improving the overall economic benefits of large farms.

To cope with complex and variable soil environments, the 622128/622129 plowshare tips typically use high-strength alloy steel or high-quality 65Mn or 60Si2Mn boron steel as the base material. Precision forging technology is employed during manufacturing to ensure continuous internal fibers and a dense structure, thus giving the product excellent overall structural strength. In terms of heat treatment, targeted quenching and tempering processes achieve a high hardness of HRC 48-55 at the cutting edge, providing extremely strong resistance to abrasive wear, while maintaining good core toughness to absorb the enormous impact forces during operation and effectively prevent breakage.

As an internationally recognized standard model, the Plow Tip 622128/622129 is perfectly compatible with various mainstream brands of moldboard plowshares, mainwalls, and tip assemblies. Whether working with sandy soil, heavy clay soil, or rocky environments, it ensures a sharp entry angle and stable tillage depth, making it a key component for improving efficiency in modern agricultural operations.
