Agricultural machinery parts, wear-resistant welded alloy plow tips, rotary tiller plow blades, 00311069, general-purpose welded plow tips.

Short Description:

This product is a welded alloy plow tip for agricultural machinery, made of high-strength alloy material with excellent wear resistance. Suitable for various types of tillage machinery, it is installed via welding, significantly improving the plow’s soil penetration and service life. Its rational structural design effectively reduces tillage resistance and improves operational efficiency, making it an ideal replacement for vulnerable parts in agricultural production.

Send email to us

Product Detail

Product Tags

The welded alloy plow tip (product number: 00311069) is a high-strength, wear-resistant component designed specifically for modern agricultural machinery. It is primarily used in tillage implements such as cultivators, hydraulic reversible plows, and rotary tillers. This product utilizes advanced welding alloy technology, depositing a high-hardness, wear-resistant layer at key soil-contact areas, significantly improving its service life and operational efficiency. It is a core wear component in farmland cultivation and land reclamation operations.

This product uses high-quality alloy steel (such as 65Mn, 60Si2Mn, or U75V) as the base material and is formed through precision forging or heat treatment processes to ensure a dense internal structure free of sand holes and pores.

At the critical contact surfaces, advanced welding technology is used to clad a layer of wear-resistant alloy with a thickness of no less than 2 mm. The hardness of the weld layer reaches over 62 HRC, significantly enhancing its resistance to soil and gravel abrasion.

Meanwhile, the product adopts a zoned heat treatment process, which maintains the ultra-high hardness of the cutting edge while ensuring that the stress-bearing parts maintain good toughness (hardness of about 44-48HRC), effectively preventing breakage due to excessive force during operation.

High wear resistance: The application of an alloy weld overlay makes the plow tip more than three times more wear-resistant than ordinary products, greatly reducing the frequency of replacement during field operations.

Long lifespan design: Some models feature a double-ended reversible design, allowing the plow tip to be reversed and used again after one end wears out, doubling its lifespan.

Wide compatibility: A complete range of product specifications are available, compatible with tractors and implements from various brands such as Foton Lovol, Kubota, and John Deere, meeting the installation needs of different agricultural machinery models.

This plow tip is suitable for various soil conditions, including dry fields, paddy fields, and hilly areas. It is mainly used for soil tillage, inter-row cultivation, land reclamation, and deep tillage. With its excellent soil penetration and wear resistance, the product has been widely used in major farms across China and exported to European and American markets such as Poland, Germany, and Denmark, receiving high praise from users.
